Structure
RCC framed structure with RCC slabs & beam system

Super structure
Internal & external walls in brick masonry 9"/4½" thick using light weight bricks.

Wall Finishes
Double coat plastering for internal & external surfaces.
Exposed internal plastered surfaces shall be finished with two coats of roller applied plastic
emulsion over smoothly prepared surface with putty. External surfaces shall be finished in acrylic
emulsion. Paints shall be of Asian paints or equivalent make

Water proofing
Water proofing shall be done in all toilets, other wet areas and open terrace areas.

Doors & windows
Main door in teak wood frame 5" x3" and teak paneled shutter to design finished in melamine polish
Doors to bedroom, toilet and kitchen in teak wood frame and flush shutters
French doors opening to sitouts in teak wood frame three track sliding system with plain glass
panels, SS mesh panel and hardware of reputed make
Windows & ventilators in teak wood frame with plain glass panels, SS mesh panel and hardware of
reputed make

Door hardware
Door hinges, tower bolts shall be SS/ brass SS coated.
Door handle & locks shall be lever type mortise locks of Dorset make or equivalent

Railings
External railings in mild steel spray enamel painted

Flooring & skirting
Foyer, drawing, living, dining and bedrooms flooring shall be in full body designer Vitrified tiles of
RAK CERAMIC/ equivalent.
Sitouts flooring in natural stone slabs.
Pathways and other hard surfaces in landscaped areas shall be in rough tandoor stone slabs
Parking area shall be in cement concrete floor

Water supply
Building water supply shall be means of gravity system from over head tank and underground water
sump with two days use storage capacity. Supply of water shall be from municipal main and bore
well. Supply from bore well shall be treated as/ requirement.
All hot and cold water supply lines shall be in CPVC of ASTRAL make or equivalent

Dado and counter tops
Dado for all toilets up to 8'-0"(lintel height) in glazed ceramic tiles of RAK CERAMICS make or
equivalent with epoxy grouting
Dado for kitchen and utility up to 2'-0" above counter level on all sides in glazed ceramic tiles of RAK
CERAMIC or equivalent make with epoxy grouting.
Toilet basin counter tops in 18mm thick grey mahogany/black variety polished granite with
polished straight edge

Drainage
Internal and external drainage lines shall be in GRADE 'B' UPVC of SUPREME make or equivalent.
All internal drainage lines shall be under deck covered with gypsum board/calcium silicate false
ceiling to facilitate serviceability

Sanitary ware & fixtures
Bedroom toilet wash basins shall be counter below type with basin mixer for hot and cold water,
angle stopcocks, towel ring
Bedroom toilet WC's shall be wall mounted type with concealed flush, health faucet and angle
stopcocks
Bedroom toilet shower areas shall be provided with concealed single lever divertor for hot and cold
water, over head shower, spout, soap dish and towel rail
Provision for geysers shall be made in all toilets and utility with angle stopcocks
Provision for solar water heater shall be made at terrace level
Sanitary ware in bed room toilets shall be of Aquado or equivalent make in white colour
Plumbing fixtures in bed room toilets and powder room shall be chrome plated of Kohler or
equivalent make.
Plumbing fixtures in servant toilet shall be chrome plated of continental model of jaquar or
equivalent make.

False ceiling
False ceiling in gypsum/calcium silicate board with GI frame work shall be provided in toilet
and utility areas to conceal under deck plumbing.
