Structure

• RCC Footing as per the structural consultant advice
• RCC frame structure with Block Work or Equivalent make.
• Concrete grade and Steel grade as per structural consultant’s advice.
• Height of each floor shall be 3.10 floor to floor.

Flooring & Tiling

• Lift Lobby and Fascia Wall &Floor using Granite
• Car Park Area : Granolithic Flooring with Grooves.
• Foyer / Living/ Dining: Vitrified Tiles size 4’X2’ (Kajaria/Somany)*
• All Bedrooms: Vitrified Tiles size 4’X2’ (Kajaria/Somany)*
• Kitchen: Vitrified Tiles size 2’X2’ and Wall Dado up-to 2’ Height (Kajaria/Somany)*
• Toilets: Ceramic Tile size 2’X1’for Floor and Walls up to Height of 8’0”.No Highlighters. (Kajaria/Somany)*
• Utility/Balconies/Step out Ceramic Tiles size 1’X1’for Floor (Kajaria/Somany)*
• Kitchen and Toilet Countertop will be finished with Black Granite.

Sanitary & Plumbing

• Sanitary Fittings: EWC Wall-hung and Wash Basins using Jaquar or equivalent Concealed Cisterns Gebrit or Equivalent make.
• Faucets: Shall be Single Lever Concealed Diverters CP finish,Jaquar or equivalent make. Provision for Hot & Cold-Water Connection shall be provided for Overhead Showers, Wash Basins and Kitchen Sink
• Plumbing: All Water Supply Lines shall be in ISI marked CPVC Pipes. Drainage Lines and Storm /
• Rainwater Drain pipes shall be in PVC.
• Kitchen: Floor/wall Mounted Faucets Taps using Jaquar/Roca or equivalent make shall be provided
• and Sink Single Bowl with Drain Board shall be provided for the kitchen
• Utility: Provision for Washing Machine shall be provided.
• Geyser Provision to be provided all toilet

Doors & Windows

• All Doors shall be of 8’0” Height.
• Main Door: Main Door Frame shall be of Seasoned Teak second quality Wood and Shutter with
• 0.35mm Thick with Moulded flush door Melamine Finishes.
• Internal Door: Solid wood frame with 30mm Thick flush door finished enamel Paint Finish.
• Hardware: All Hardware shall be in Chrome Plated Finish, Tower Bolts, Door Stoppers,
• Hinges.Cylindrical Locks for Internal Doors and Mortise Type for Main Door as per Architect Design – Godrej/ Dorset make or Equivalent.
• Window Shutters & Ventilators: UPVC Sliding Windows Veka brand or Equivalent make with 5mm
• Glass shall be provided
• Staircases: Tile with Mild Steel
• Digital lock provided at Main door

Electrical

• Concealed Copper Wiring using Orbit/Finolex Cables or Equivalent make.
• Wiring shall be done for Lighting, 5Amps, 15 Amps and AC points in the Apartment as per Point
• Matrix shared in the agreement.
• Switches: All Switches shall be Legrand/Litaski or Equivalent make.
• Generator: 100% Backup Power is provided for the Lift and Common Areas , Apartments to be provided with 6Kva Power.
• Adequate ELCB and MCB shall be provided in each Apartment.
• Concealed Copper Piping, Drain Pipe and Electrical Provision for Air Conditioners will be provided in Bedrooms, Hall/Dining.
• One Termination Point for Telephone/Data, DTH shall be provided.
• 12w LED Round Light Fittings would be provided for Entire Apartment and Common Area.
• Provision for EV (Electrical Vehicle) charging point in the Designated Parking Lot.
• Geyser Point to be provided all toilet
• Equivalent
