FOUNDATION :
Foundation - R.C.C. footing with framed structure
Depth - 5ft (Depends based on the Soil test report)
Reinforcement - structural consultant designs.
The concrete mix – M 20
P.C.C. – M 10
Basement height - 3’0”

SUPER STRUCTURE :
Outer walls - 9” thk
Cement Mortor 1: 5
Partion walls 4½” thk
Cement Mortor 1:3
Lintel height 7 Feet
Window Sunshade -1’9” wide
Loft - one side loft in Bed room and Kitchen – 1’9”
Roof height - Roof to Roof - 10 feet
Roof slab – Thick as per Structural consultant
Parapet wall - 3’ height from Roof level
Weathering course - brick jelly with Lime concrete
Pressed Tiles or country Tile
Plastering – Internal – 1: 4 cm
Plastering – External – 1.5 cm
Ceiling - 1: 3 cm with smooth finishing

ELECTRICAL :
Wiring
Light points - 1/18 wire. Finolex make or Equivalents quality
5 amps plug point - 3/20 wires.
15 amps plug points - 7/20 wires.

Switches
Anchor/ Litaski (deluxe) / Legarant
(Modular switches will be provided)
Circuit breakers - S.M.B. boxes.
U P S Wiring for all Flats

JOINERIES :
Main door - First quality teak paneled door.
Door frame - 5”x 3”thk
Lock - Godrej night latch / Europa
Other doorframes - 4”x 2 ½ first qualities Kongu / Padak frame
Windows - M.S grills for safety.
Windows - 4”x 2 ½ first quality Kongu / Padak frame / Aluminum Frame
Main Door Safety Gate.

PAINTING :
Inner walls – Emulsion paint - Two coats with Wall patty Finish
External Walls - Emulsion paint ACE / ICI Dulux
Wood surfaces - primer, patty and two coats of Asian/ ICI enamel paint.
Grill surfaces - Enamel paint - Two coats

PLUMBING :
Toilet concealed plumbing
Pipe 15mm ‘B’ class G.I. (hot & cold) / PVC
Common toilet - I.W.C
Attached toilet - E.W.C
All PVC fittings confine to ISI (star brand / Finolex)

TILING & FINISHING :
Cost not exceeding Rs. 40/-
Main flooring first quality tiles of regular series
Skirting - 4” of the same flooring tile.
Bathrooms Tiled up to 7’0’ht.
Kitchen - 19mm tk 1’9” width black granite
Sink - Stainless steel/ granite
Tiling 2’ height from the Granite platform
Sanitary wares - white (Parry ware / Hind ware)
C.P. Fittings - waterman/ metro/ Novaa / Ess Brand Taps of regular type.
