Civil Works

• R.C.C. Framed structure using columns and beams as per as the Structural design.
• Excavation : Column foundation with 5’0” depth Basement raised level will be raised up to 2’0” from the existing road level.
• All external walls with 6” thick Solid block and internal 4” thick Solid block.
• R.C.C. work of M-20 Grade ( with a roof height of 10’0”) One Loft will be provided on the shorter side of all bedrooms and in kitchen.
• Parapet wall consist of 4” Solid Block up to the height of 2’ 0” External Plastering in C:M 1:5 with sponge finished surface.
• Internal Plastering in C:M 1:5 with smooth finished surface Internal

Electrical Works

• Concealed electrical conduits with metal boxes.
• All Electrical cables will be of Orbit Brand.
• Necessary MCB’s with Isolator will be provided Switches-Local Switches All wiring will be concealed and Designed for 3 phase power supply.

Plumbing Works

• Internal Plumbling line will be concealed with ½” CPVC pipes-Un Brand and PVC pipe with Un Brand.
• SS finished CP fittings will be provided One White EWC/IWC of local brand white color will be provided in each toilet.
• 2 in 1 wall mixer & one shower point will be provided in each toilet.
• One white wash basin 12” x 18” size will be provided in each toilet.
• Necessary floor sump, man hole with cover will be provided for external sewage.

Tiles Work

• Flooring-Vitrified double charge 2’x2’ flooring @ Cost of Rs.40 rs /sq ft for all Bedrooms, Hall, Kitchen and Dining.
• Toilets wall tile will be done up to 7’0” height (Rs.30/-) of approved color and Anti-skid tiles for flooring.
• Kitchen counter slab will be provided with Granite of rate 100 rs / sq ft and stainless steel sink of rate 2000 Rs will be provided with 2’0” height wall tiles of range 30 Rs/Sq ft above the counter.
• Staircase area-Tile flooring 1”x 1” with MS Hand Railing.

Carpentary Works

• Main Door-Flush Door with Veneer, Sal wood frame of size 5”x 3” , worth Rs 15000 including Fittings.
• Internal Doors – Enamel Painted Skin Panel Door and Frame of size 4”x3” worth Rs 9000 including Fittings.
• First Quality PVC doors for Toilets-Basic cost 2500 Rs.
• All windows will be of sliding white powder coated Aluminiumwith 5mm thick plain glass and fixed grill of 12mm square rod at a spacing of 5”x5” c/c.
• Ventilators of Aluminium (Louver type ) with necessary glass.
• Plumbing Works Electrical Works Specifications

Paintings

• Internal Wall - 2 Coat Putty, 1 Coat Primer with 2 Coats of Tractor Emulsion Paint.
• Ceiling-1 Coat white Cement and 2 Coat Tractor Emulsion Paint.
• Exterior Wall-1 Coat of Dr Fixit Primer and 2 Coat Ace Emulsion Paint.
• Main Door-Fully teak wood varnish. Other Doors and Grills-Enamel Pain
