Foundation:
Reinforced cement concrete structure of under reamed pile foundation.

Structure:
The entire external and internal wall will be of 9’’ and 4.5’’ thick brick wall as working drawing. Height of door little will be 7’0’’ and ceiling height 10’ from the plinth level.

Door Window:
All the door frame will be made of wooden(sal). Main door wooden, remaining doors -32mm thick phenol bonded hot steamed pressed flush doors. Painted two coats of enamel paint with necessary fitting and fixture. All the windows will be made of aluminum sliding.

Flooring:
All the drawing – dining hall, bedroom, kitchen and passage will be vitrified tiles. All the toilet shall have ceramic tiles flooring and dado on wall uo to 6’ height of glazed tiles.

Kitchen:
Kitchen platform will be 2’ wide finished with green marble and dado wall up to 2’ wide glazed tiles. Provision for exhaust fan opening only.

Sanitary:
Each toile will be indian –orrisa pan with flushing arrangement.

Water supply:
Hot and cold pipe installation in toilet. Two point arrangement in kitchen sink.

Painting:
External face of the building will be two coats of cement based paint.

Electrical:
All the concealed copper electrical writing will be up to meter-board only and wiring will be provided for single face.

Grills:
Iron grills of medium weight in windows and ventilators.

Over head water tank:
P.V.C. tank of 500 lt. capacity.

Parapet wall:
4’’ thick wall up to 2’6’’ height.
